Carbon Steel CFB Boiler Industrial Cyclone Separator Stable Performance cyclone collector
Industrial Cyclone Separator Description
1. A cyclonic separation is a method of removing particulates from an air, gas or liquid stream, without the use of filters, through vortex separation. When removing particulate matter from liquid, a hydrocyclone is used; while from gas, a gas cyclone is used. Rotational effects and gravity are used to separate mixtures of solids and fluids. The method can also be used to separate fine droplets of liquid from a gaseous stream.
2. A high speed rotating (air)flow is established within a cylindrical or conical container called a cyclone. Air flows in a helical pattern, beginning at the top (wide end) of the cyclone and ending at the bottom (narrow) end before exiting the cyclone in a straight stream through the center of the cyclone and out the top. Larger (denser) particles in the rotating stream have too much inertia to follow the tight curve of the stream, and thus strike the outside wall, then fall to the bottom of the cyclone where they can be removed. In a conical system, as the rotating flow moves towards the narrow end of the cyclone, the rotational radius of the stream is reduced, thus separating smaller and smaller particles.
3. The cyclone geometry, together with volumetric flow rate, defines the cut point of the cyclone. This is the size of particle that will be removed from the stream with a 50% efficiency. Particles larger than the cut point will be removed with a greater efficiency, and smaller particles with a lower efficiency as they separate with more difficulty or can be subject to re-entrainment when the air vortex reverses direction to move in direction of the outlet.
1. The collected product remainls dry
2. Can handle sticky and tacky solids with proper liquid irrigation
3. Low maintenance cost
4. Very compact in most applications
5. Can be used under very extreme processing conditions
6. No moving parts
7. Constant Pressure Drop
8. Can be equipped with erosion or corrosion resistant
9. Can be fabricated with plate metal
10. Separate liquid or solid particulates,sometiome both in combination with proper design
Specification
1. Cyclonic separation is a method of removing particulates from an air, gas or liquid stream, without the use of filters, through vortex separation.
2. When removing particulate matter from liquids, a hydrocyclone is used; while from gas, a gas cyclone is used.
3. Rotational effects and gravity are used to separate mixtures of solids and fluids.
4. The method can also be used to separate fine droplets of liquid from a gaseous stream.
5. Cyclonic separation can eliminate particulates, such as dirt and dust, from a stream of air, gas or liquid. Engineers sometimes call these tornadic dust busters centrifugal separators. That's because at the root of these machines is something called centrifugal force.
Product Display
